ASTM D1559 , ASTM D 6926 , AASHTO T 245 , NF P98 , 251-2, AS 2891.5
With Inverter for faster blow rate for Australian Standards
Consists of:
-frame with a wooden block,
-stable holding device for the set of molds
-pull-up device for the drop hammer.
.
The drop weight is lifted by a chain and an electric gear motor.
The number of beats is set on a preset counter.
After reaching the preselected number of strokes, the motor stops automatically.
Sample diameter 101.6 mm

Excludes concrete base and Moulds- see 20-1480
…
Dimensions approx.: 550 x 460 x 1350 mm
Weight approx: 95 kg
Electric data: 400 V, 50 Hz, 3 P+N+PE
