Used in various area such as materials Portland cement clinker, chemicals, construction materials, fertilizers, fillers, grains, metal powders, minerals, nut, sand, soil, dust washing etc.

The added material is divided equally into the buckets which rotating in a “circle” motion.

Specification

-The grain size capacity of the Rotary Sample Divider is 0-20 mm
-Sample buckets are made of 304 stainless steel
-Optional 8 divisions, or 12 divisions chambers in triangular prism shape. Other options are available
-The feeding hopper is made of 304 stainless steel, and the other parts are made of electrostatic powder paint on steel.

-Sample buckets have handles to easy and safe carrying.

-Feeding speed and quantity are variable adjustable with the help of magnetic vibration system.

-Dividing speed of sample buckets can be adjusted between 0 and 60 rpm with electronic speed control panel and can be viewed via digital screen on the device during the test.
-Power supply 220 V, 50-60 Hz, 1 ph
