-Operation by remote control for workers safety
-Electrical drilling device (light weight version) with braked axle
-High performace water cooled electical drilling engine with RPM 180-1370 1/min with 18 steps and display Stepless,
-Load dependent electrical vriable Drilling feed – (no hydraulic power pack required)
-3 Jack, electrical driven, for level adjustment in two axes
-320l Water Storagetank
-LCD-Display for water level 0-100%
-Additional fast coupling for cleaning devices
-Rigid, corrosion resitstant aluminium frame
-Whole lining and accessories varnished aluminium plate
-Electrical Emergency Stop Function
-Night Working light for LED for low power consumption
-Integrated LED Beacon and warning light
.
Rechargeable Battery Pack:
Inclusive 24V LiFePO4 Smart-battery pack with 5120 Wh capacity
Bluetooth-App for observation voltage and temperature
LCD-Display for battery status (% or Ah), Remaining time, current status and voltage
Integrated Charge Controller with inverter (230 V)
.
Includes
-Recharging cable for 230 V socket
-Electrical power socket for additional devices (max. 3 kW, during off operation of machine)
-Rigid linear guidings with trapezoidal spindle made of stainless steel with a drilll feed of 800 mm
.
Technical Data:
Drilling Travel: 800 mm
Max. tow bar load: 50 kg
Weight (empty): < 550 kg Weight (total): < 750 kg Dimension: Length: 2100 mm (3300 mm total lenght with drawbar trailer) Width: 1620 mm Height: 2000 mm (includ. beacon)
